J-3045.in - 45° & 90° (Semi Auto)

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.

Details	Unit	J-3045.in (45° & 90°)
Table size (L x B)	mm	1150 x 900
Minimum work piece length	mm	280
Work piece thickness range
- Inclined 45° edge	mm	10-25
- Full straight edge	mm	10-25
Edge banding thickness for PVC / ABS in coil form
- Inclined 45° edge	mm	0.4 - 1.5
- Full straight edge	mm	0.4 - 2.0
Min-radius for curved edging	mm	20
Glue pot capacity	kg	3
Variable feed	m/min.	4 to 12
Front table adjustment (up & down)	mm	3
Front table tilt angle	Degree	0° to 45°
Maximum setting temperature	°C	180°
Compressed air requirement	hp/kg/cm²	0.5 / 5.7
Heating element	kw	1.5
45° Tape groove motor	kw	0.73
Electric motor	kw	0.37 (415V, 3Ø)
Power supply	voltage/Ø	415V, 3Ø
Total power	hp	3.5
Machine dimension (L x B x H)	mm	2150 x 1100 x 1080
Approx. net weight	kg	330
